• Provides power & data connection for up to 24 PoE network devices;• Save installation cost by delivering data & power over existing network cables;• 10/100/1,000 auto-sensing ports automatically detect optimal network speeds;• Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification;• 2 small form-factor pluggable 10 GbE SFP/SFP module slots;• IEEE 802.3at/af-compliant RJ45 PoE/PoE output ports;• Power output up to 30 watts per port;• PoE power budget of 400W;• Supports IEEE 802.3at & IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras);• Supports IEEE 802.3at/af detection & short circuit, overload & high-voltage protection;• All RJ45 ports with auto-MDIX & NWay auto-negotiation support;• Supports link aggregation (trunking);• IEEE 802.3x flow control for full duplex;• Trunking for SFP1 & SFP2 can be activated via switch on front panel;• Full/half duplex operation;• Flow control can be activated via switch on front panel;• Store & forward switching architecture;• Supports jumbo frames up to 9KB;• 88Gbps switch fabric;• Supports 16k MAC address entries;• 1.5MB buffer memory;• LEDs for power, link/activity & PoE;• 2 high-volume cooling fans ensure perfect ventilation;• Includes 19 rack-mount brackets;• 3-year warranty;
HEIGHT X LENGTH X WIDTH: 3.1 X 23.5 X 15.2
WARRANTY: THREE YEAR
RETURNABLE: Yes
