Product Details
＋
Highlights
- 5× 10/100/1000 Mbps auto-negotiation RJ45 ports, supports Auto-MDI/MDIX
- Plug and play, no configuration, no management required
- Supports 802.1p/DSCP QoS and IGMP Snooping functions
- Durable metal enclosure, desktop/wall mounting options, and fanless design
- IEEE 802.3x flow control provides reliable data transmission
- Green Ethernet technology reduces power consumption
- Monitor and resolve loop-related issues in the network structure to prevent interruptions caused by loops
Specifications
| HARDWARE SPECIFICATIONS | |
|---|---|
| standards and protocols | IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p |
| Connection interface | 5× 10/100/1000 Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports |
| Number of fans | Fanless |
| External power supply | External Power Adapter (Output: 5 V DC / 0.6A) |
| LED indicator light |
• Power • Link/Act indicators per port built into each RJ-45 port |
| Dimensions (length x width x height) | 3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm) |
| Maximum power consumption | 3.1 W (220V/50Hz) |
| Maximum heat dissipation | 10.57 BTU/h |
| PRODUCT PERFORMANCE | |
|---|---|
| Packet forwarding rate | 7.4 Mpps |
| MAC address table | 2K |
| packet buffer memory | 1MB |
| jumbo frame | 16 KB |
| SOFTWARE SPECIFICATIONS | |
|---|---|
| Advanced functions |
• Green Ethernet technology • 802.3X Flow Control • 802.1P/DSCP QoS • IGMP Snooping • Loop Prevention |
| Transmission mode | Store and Forward |
| OTHER SPECIFICATIONS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents |
• DS105G • Power Adapter • Installation Guide |
| environment |
• Operating Temperature: 0–40 °C (32–104 °F) • Storage Temperature: -40–70 °C (-40–158 °F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
