Product Details
＋
Ubiquiti Unifi Switch 48 PoE (500W) US-48-500W (1 Year Manufacture Local Warranty In Singapore) -EOL
Layer 2, PoE switch with
(48) GbE, 802.3at PoE and 24V passive PoE RJ45 ports,
(2) 1G SFP ports, and
(2) 10G SFP ports.
The Switch 48 PoE 500W (US 48 PoE 500W), a fully managed switch with (48) GbE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP ports. Each of the switch's ports can provide either 802.3at PoE or configurable, 24V passive PoE to UniFi access points or other PoE devices. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
- (48) GbE, 802.3at PoE and 24V passive PoE RJ45 ports
- (2) 1G SFP ports
- (2) 10G SFP ports
- 500W total PoE supply
Managed with the UniFi Network application
Video Review
Technical Specifications
| US-48-500W | |
|---|---|
| Dimensions | 485 x 43.7 x 374.6 mm (19.09 x 1.72 x 14.75") |
| Weight | 6.1 kg (13.5 lb) |
| Networking Interfaces | ((48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
| Management Interface | (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band |
| Total Non-Blocking Throughput | 70 Gbps |
| Switching Capacity | 140 Gbps |
| Forwarding Rate | 104.16 Mpps |
| MAC Address Table | 16384 |
| Maximum Aggregations | 6 |
| Monitoring Sessions | 1 |
| Maximum VLANs | 255 |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 500W DC |
| Max. Power Consumption Including PoE Output Excluding PoE Output |
500W 64W |
| LEDs Per Port RJ45 Data Ports SFP Data Ports |
PoE, Speed/Link/Activity Speed/Link/Activity |
| Sound Level* Fan Level 0 Fan Level 1 Fan Level 2 Fan Level 3 |
10.7 dBr 16.2 dBr 19.3 dBr 23.6 dBr |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| PoE Per Port | |
| PoE Interfaces | PoE IEEE 802.3af/at (Pins 1, 2 ; 3, 6-) 24VDC Passive PoE (Pins 4, 5 ; 7, 8-) |
| Max. PoE Wattage per Port by PSE | 34.2W |
| Voltage Range 802.3at Mode | 50–57V |
| Max. Passive PoE Wattage per Port | 17W |
| 24V Passive PoE Voltage Range | 20-27V |
* Background noise level: 27.5 dBa
