Ubiquiti Unifi Switch Pro 24 PoE USW-Pro-24-PoE (1 Year Manufacture Local Warranty In Singapore)
Layer 3, PoE switch with
(24) GbE RJ45 ports, including
(16) 802.3at PoE ports and
(8) 802.3bt PoE ports, and
(2) 10G SFP ports.
The Switch Pro 24 PoE (USW Pro 24 PoE) is a fully managed switch with (16) GbE, 802.3at PoE RJ45 ports, (8) GbE, 802.3bt PoE RJ45 ports, and (2) 10G SFP ports. The USW Pro 24 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 24 PoE is the ideal access layer switch for any UniFi system. It combines up to 400W of PoE power with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
- (1) 1.3" LCM color touchscreen with AR switch management
- (16) GbE, 802.3at PoE RJ45 ports
- (8) GbE, 802.3bt PoE RJ45 ports
- (2) 10G SFP ports
- (1) USP RPS DC input
- 400W total PoE supply
- Near-silent cooling
- Layer 3 switching features
Managed with the UniFi Network application: Version 5.10.5 and later
Video Review
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72") |
| Weight With Rackmount Brackets |
4.30 kg (9.48 lb) 4.39 kg (9.68 lb) |
| Interfaces Networking Management |
(24) 10/100/1000 RJ45 Ports (2) 1/10G SFP Ethernet Ports Ethernet In-Band |
| Total Non-Blocking Throughput | 44 Gbps |
| Switching Capacity | 88 Gbps |
| Forwarding Rate | 65.472 Mpps |
| Power Method Universal Input USP RPS DC Input |
100-240VAC/50-60 Hz 52VDC, 7.69A; 11.5VDC, 2.61A |
| Power Supply | AC/DC, Internal, 450W |
| Supported Voltage Range | 100 to 240VAC |
| Max. Power Consumption (Excluding PoE Output) | 50W |
| LEDs System RJ45 Data Ports SFP Data Ports |
Status PoE; Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| PoE | |
| Total Available PoE | 400W |
| PoE Interfaces Ports 1-16 Ports 17-24 |
POE IEEE 802.3af/at, (pins 1, 2 ; 3, 6-) 60W PoE IEEE 802.3af/at/bt (Pins 1, 2 ; 3, 6-) (Pair A 1, 2 ; 3, 6-) (Pair B 4 , 5 ; 7, 8-) |
| Max. PoE Wattage per Port by PSE 802.3at 802.3bt |
32W 64W |
| Voltage Range 802.3af Mode | 44-57V |
| Voltage Range 802.3at Mode | 50-57V |
*Background noise level: 27.5 dBa
